Opis
Snaga sustava: 29 / 38 W, Svjetlosni tok: 3.200 lm pri 29 W / 4.200 lm pri 38 W (podesivo kliznim prekidačem), Temperatura boje: 4.000 K (neutralno bijela) / 3.000 K (toplo bijela) (podesivo kliznim prekidačem), Nije prigušivo, Viševatno i višelumensko, Radni napon: AC 230 V / DC 186 - 260 V, Frekvencija: 50 Hz, Kut snopa: 110°, Uzvrat boja: CRI> 80, Materijal kućišta: polikarbonat, Klasa zaštite: IP20 montaža na zid / IP54 montaža na strop, Vijek trajanja: 40.000 sati / L80, Dva stražnja kabelska ulaza za prolazno ožičenje, Konektori između zidne montaže i tijela svjetiljke, Brzo spajanje putem priključnog terminala, Brza instalacija putem odvojivog zidnog nosača, Moguća površinska i ugradbena montaža,
Ovaj tekst je strojno preveden.
Dokumenti
Tehnički podaci
| Vrsta proizvoda |
LED stropna svjetiljka |
|---|---|
| Boja |
bijela |
| Klasa energetske učinkovitosti |
D (A - G) |
| Protection class according to IEC 61140 |
II |
| Width |
400 mm |
| Connection type |
Push-in clamp |
| Housing colour |
White |
| Voltage type |
AC/DC |
| With movement sensor |
FALSE |
| Type of grid |
None |
| Type of control gear |
Not required |
| Colour rendering index CRI |
80-89 |
| Suitable for wall mounting |
TRUE |
| With light sensor |
FALSE |
| Suitable for suspended mounting |
FALSE |
| Length |
400 mm |
| Height/depth |
63 mm |
| Housing material |
Plastic |
| Lamp type |
LED not exchangeable |
| Suitable for light line configuration |
FALSE |
| Light outlet |
Direct |
| Light distribution |
Symmetric |
| Material cover |
Plastic, opal |
| Impact strength |
IK10 |
| Nominal voltage |
230-230 V |
| Emergency power supply integrated |
FALSE |
| Degree of protection (IP) |
IP54 |
| With light source |
TRUE |
| Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24 |
FALSE |
| Covering of the luminaire with thermally insulating material possible |
FALSE |
| Suitable for number of light sources |
1 |
| Suitable for built-in mounting |
FALSE |
| With control gear |
TRUE |
| Suitable for workplace according to EN 12464-1 |
FALSE |
| Beam angle |
> 80° - Extreme wide beam |
| Colour temperature |
3000-4000 K |
| Max. system power |
38 W |
| Rated luminous flux according to IEC 62722-2-1 |
4200 lm |
| Colour of light |
White |
| IFTTT support available |
FALSE |
| Type of wiring |
Suitable for loop-through wiring |
| Rated lifetime L70/B50 at 25 °C |
40000 h |
| Filament test according to IEC 60695-2-11 |
None |
| Dimming 0-10 V |
FALSE |
| Dimming 1-10 V |
FALSE |
| Dimming DALI |
FALSE |
| Dimming DMX |
FALSE |
| Dimming potentiometer (integrated) |
FALSE |
| Dimming LineSwitch |
FALSE |
| Dimming manufacturer's proprietary system |
FALSE |
| Dimming mains voltage modulation |
FALSE |
| Dimming phase cut-off (trailing edge) |
FALSE |
| Dimming phase cut-on (leading edge) |
FALSE |
| Dimming programmable |
FALSE |
| Dimming RF |
FALSE |
| Dimming Sine Wave Reduction |
FALSE |
| Dimming Touch and Dim |
FALSE |
| Dimming Zigbee |
FALSE |
| Dimming with push-button |
FALSE |
| No dim function |
TRUE |
| Light distributor |
Diffuser lens/optic/panel |
| Dimming DSI |
FALSE |
| Operation by Bluetooth |
FALSE |
| Compatible with Apple HomeKit |
FALSE |
| Compatible with Google Assistant |
FALSE |
| Compatible with Amazon Alexa |
FALSE |
| Dimming DALI-2 |
FALSE |
| Colour of light adjustable |
Positions |
| Luminous flux adjustable |
Positions |
| Beam angle adjustable |
No |
| Exchangeable control gear |
FALSE |
| Compatible with Casambi |
FALSE |
| Energy efficiency class of the light source according to EU regulation 2019/2015 |
E |
| Suitable for ceiling mounting |
TRUE |
| Surface protection housing |
Untreated |
