Phoenix Contact 1411894 N/A 1 St.

Marka Phoenix Contact

(0 ocen)

33,99 EUR

(= 256,10 kn)

Proizvajalčeva koda: 1411894

EAN koda: 4046356944625

Registrirana blagovna znamka: Phoenix Contact

Ime proizvajalca: PHOENIX CONTACT Deutschland GmbH

Naslov proizvajalca: Flachsmarktstr. 8

Poštna številka proizvajalca: 32825

Kraj proizvajalca: Blomberg

Država proizvajalca: Germany

Telefon proizvajalca: +4905235300

Elektronski kontakt proizvajalca: https://www.phoenixcontact.com/

Kontakt odgovorne osebe za varnost: [email protected]

Država odgovorne osebe za varnost: Nemčija

Proizvođač-br. dijela	1411894
Sadržaj	1 St.
Broj polova	5
Tip	SACC-M12FR-5CON-PG 9-SH ADH
Vrsta zaštite	IP67
Zaštićeno	da
Maks. temperatura	85 °C
Min. temperatura	-40 °C
Type of locking	Other
Rated voltage	60 V
Screened	TRUE
Contact type	Other
Housing material	Other
Coating housing	Other
With status indication	FALSE
Ambient temperature	-40-85 °C
Inflammability class of insulation material according to UL94	HB
Type of electric connection	Screw connection
Material of contact surface	Gold
Overvoltage category	II
Pollution degree	3
Type of housing	Angled
Connectable conductor cross section solid-core	0.25-0.75 mm²
Connectable conductor cross section fine-strand with cable end sleeve	0.25-0.75 mm²
Connectable conductor cross section fine-strand without cable end sleeve	0.25-0.75 mm²
Connectable conductor cross section multi-wired	0.25-0.75 mm²
Degree of protection (IP), mounted	IP67
With protective conductor	FALSE
Rated current In	4 A
Min. number of insertion cycles	50
Number of power contacts	0
Number of control contacts	5
Number of data contacts	0
Material thread ring	Other
