YR 2x0,8 oplašteni vod 100 m

(0 ocen)

53,99 EUR

(= 406,79 kn)

Kod proizvoda: 2984904
EAN: 2050009581268
Procijenjena isporuka:14.10.2026 - 16.10.2026

Opis

YR PVC zvonasti kabel, preklopne žice izolirane PVC-om, jednožilne, nazivni napon 100 V, temperaturni raspon -5°C do +70°C, za fiksnu instalaciju kao izolacijski kabel na i ispod žbuke, nije za instalaciju jake struje namjene, za prijenos signala u telekomunikacijskim i portafonskim sustavima itd

Ovaj tekst je strojno preveden.

Varnost izdelkov (GPSR)

Proizvajalčeva koda: YR 2x0,8

EAN koda: 2050009581268

Registrirana blagovna znamka:

Ime proizvajalca: Conrad Electronic SE

Naslov proizvajalca: Klaus-Conrad-Str. 1

Poštna številka proizvajalca: 92240

Kraj proizvajalca: Hirschau

Država proizvajalca: Germany

Telefon proizvajalca: +499604408787

Elektronski kontakt proizvajalca: [email protected]

Kontakt odgovorne osebe za varnost: [email protected]

Država odgovorne osebe za varnost: Nemčija

Dokumenti

Upute za rad i sigurnost 2984904 YR 2x0,8 oplašteni vod 100 m

Tehnički podaci

Sadržaj	100 m
Proizvođač-br. dijela	YR 2x0,8
Tip	YR 2x0,8
Nominal cross section conductor	0.8 mm²
Material core insulation	Polyvinyl chloride (PVC)
Core identification	Colour
Weight	25 kg/km
Flame retardant	No
Circuit integrity	None
Nominal voltage U	100 V
Colour outer sheath	White
Shape of conductor	Round
Diameter conductor	0.8 mm
Conductor material	Copper
Material outer sheath	Polyvinyl chloride (PVC)
Conductor category	Class 1 = solid
Armouring/reinforcement	None
Permitted cable outer temperature after assembling without vibration	-5-70 °C
Core colour	Several
Screen	FALSE
Number of cores	2
Insulation integrity	None
Max. permitted conductor temperature	70 °C
Protective barrier	None
Outer diameter approximate	4.2 mm
With protective conductor	FALSE
Low smoke (according to EN 61034-2)	FALSE
Halogen free according to EN 60754-1/2	FALSE
Oil resistant according to EN IEC 60811-404	FALSE
Low temperature resistant according to EN 60811-504+505+506	FALSE
Conductor surface	Bare
Reaction-to-fire according to EN 13501-6: Class	None
Reaction-to-fire according to EN 13501-6: Smoke production	None
Reaction-to-fire according to EN 13501-6: Flaming droplets/particles	None
Reaction-to-fire according to EN 13501-6: Acidity	None
Min. permitted bending radius, stationary application/permanent installation	30 mm
Twisted cores	FALSE
Cable geometry	Round
Certified for shipboard application	FALSE
Suitable as medium-voltage cable	FALSE
Suitable as high-voltage cable	FALSE
Certified as airport lighting cable	FALSE
Vrsta proizvoda	oplašteni vod
