RZB 221126.002.3.19 zidna svjetiljka

Marka RZB

(0 ocen)

119,99 EUR

(= 904,06 kn)

Kod proizvoda: 2978536
EAN: 4010319928373
Procijenjena isporuka:15.10.2026 - 19.10.2026

Opis

Ukrasno okruglo nadgradno svjetlo za unutarnju i vanjsku upotrebu. Plastični spoj. Difuzor od opalne plastike (polikarbonat), otporan na udarce. Pričvršćivanje difuzora sustavom opruga. Pogodan za stropnu montažu, zidnu montažu. S integriranim HF detektorom pokreta. HF detektor 5,8 GHz ISM frekvencijski pojas. Osjetljivost/doseg: 1-8 m u promjeru, podesivo od 20-100%. Kontrola vremena podesiva od 1 sekunde do 15 minuta u 8 razina. Područje detekcije: 120° Kao glavno svjetlo do 800 W (omsko opterećenje), 500 W (fluorescentna svjetiljka, LED) / 400 A, 200 µs početne struje. Samo djelomično pogodan za vanjsku upotrebu zbog osjetljive reakcije na sve pokrete. IP 43 montaža na strop, IP 44 montaža na zid.

Ovaj tekst je strojno preveden.

Varnost izdelkov (GPSR)

Proizvajalčeva koda: 221126.002.3.19

EAN koda: 4010319928373

Registrirana blagovna znamka: RZB

Ime proizvajalca: RZB Rudolf Zimmermann, Bamberg GmbH

Naslov proizvajalca: Rheinstrasse 16

Poštna številka proizvajalca: 96052

Kraj proizvajalca: Bamberg

Država proizvajalca: Germany

Telefon proizvajalca: +4995179090

Elektronski kontakt proizvajalca: http://www.rzb-leuchten.de

Kontakt odgovorne osebe za varnost: [email protected]

Država odgovorne osebe za varnost: Nemčija

Dokumenti

Upute za rad i sigurnost 2978536 RZB 221126.002.3.19 zidna svjetiljka

Tehnički podaci

Vrsta proizvoda	zidna svjetiljka
Klasa energetske učinkovitosti	n.rel. (EENRPS00)
Protection class according to IEC 61140	I
Outer diameter	305 mm
Lamp holder	E27
Conductor cross section	6 mm²
Connection type	Screwed terminal
Housing colour	White
Voltage type	AC/DC
With movement sensor	FALSE
Suitable for lamp power	45-45 W
Type of grid	None
Type of control gear	Not required
With light sensor	FALSE
Suitable for suspended mounting	FALSE
Number of poles	3
Height/depth	115 mm
Housing material	Plastic
Lamp type	Incandescent lamp
Suitable for light line configuration	FALSE
Suitable for emergency lighting	TRUE
Light outlet	Direct/indirect
Light distribution	Symmetric
Material cover	Plastic, opal
Impact strength	IK10
Nominal voltage	0-250 V
Emergency power supply integrated	FALSE
Degree of protection (IP)	IP43
With light source	FALSE
Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24	FALSE
Suitable for number of light sources	1
Suitable for wall mounting	TRUE
Suitable for built-in mounting	FALSE
With control gear	FALSE
Suitable for workplace according to EN 12464-1	TRUE
Suitable for surface mounting	TRUE
Beam angle	> 80° - Extreme wide beam
Nominal current	180-180 mA
Max. system power	45 W
With air slots	FALSE
Constant light output (CLO)	FALSE
IFTTT support available	FALSE
Type of wiring	Suitable for loop-through wiring
Degree of protection (NEMA)	Other
Rated ambient temperature according to IEC 62722-2-1	25-25 °C
Filament test according to IEC 60695-2-11	850 °C - 30 s
Dimming 0-10 V	FALSE
Dimming 1-10 V	FALSE
Dimming DALI	FALSE
Dimming DMX	FALSE
Dimming potentiometer (integrated)	FALSE
Dimming GPRS	FALSE
Dimming LineSwitch	FALSE
Dimming manufacturer's proprietary system	FALSE
Dimming mains voltage modulation	TRUE
Dimming phase cut-off (trailing edge)	FALSE
Dimming phase cut-on (leading edge)	FALSE
Dimming programmable	FALSE
Dimming RF	FALSE
Dimming Sine Wave Reduction	FALSE
Dimming Touch and Dim	FALSE
Dimming Zigbee	FALSE
Dimming with push-button	FALSE
No dim function	TRUE
Light distributor	None
Dimming depending on control gear	FALSE
Dimming DSI	FALSE
Unified Glare Ratio (UGR)	18.90
Operation by Bluetooth	FALSE
Compatible with Apple HomeKit	FALSE
Compatible with Google Assistant	FALSE
Compatible with Amazon Alexa	FALSE
Dimming DALI-2	FALSE
Colour of light adjustable	No
Luminous flux adjustable	No
Beam angle adjustable	No
Exchangeable control gear	FALSE
Suitable for ceiling mounting	TRUE
Surface protection housing	Other
Power factor	1
