Varnost izdelkov (GPSR)
Proizvajalčeva koda: C25N4
EAN koda: 3606481999887
Registrirana blagovna znamka: Schneider Electric
Ime proizvajalca: Schneider Electric GmbH
Naslov proizvajalca: Gothaer Str. 29
Poštna številka proizvajalca: 40880
Kraj proizvajalca: Ratingen
Država proizvajalca: Germany
Telefon proizvajalca: +4921173743000
Elektronski kontakt proizvajalca: https://www.se.com/
Kontakt odgovorne osebe za varnost: [email protected]
Država odgovorne osebe za varnost: Nemčija
Dokumenti
Podatkovna tablica 2927984 Schneider Electric C25N4 učinski prekidač 1 St.
Podatkovna tablica 2927984 Schneider Electric C25N4 učinski prekidač 1 St.
Upute za rad i sigurnost 2927984 Schneider Electric C25N4 učinski prekidač 1 St.
Upute za rad i sigurnost 2927984 Schneider Electric C25N4 učinski prekidač 1 St.
Tehnički podaci
| Vrsta proizvoda |
učinski prekidač |
|---|---|
| Tip |
C25N4 |
| Sadržaj |
1 St. |
| Number of auxiliary contacts as normally open contact |
0 |
| Number of auxiliary contacts as normally closed contact |
0 |
| Rated permanent current Iu |
250 A |
| Number of poles |
4 |
| Number of auxiliary contacts as change-over contact |
0 |
| Degree of protection (IP) |
IP40 |
| Position of connection for main current circuit |
Front side |
| Motor drive integrated |
FALSE |
| Type of electrical connection of main circuit |
Screw connection |
| Type of control element |
Wing knob |
| With switched-off indicator |
TRUE |
| Rated short-circuit breaking capacity Icu at 400 V, 50 Hz |
50 kA |
| Suitable for DIN rail (top hat rail) mounting |
FALSE |
| Integrated earth fault protection |
FALSE |
| Motor drive optional |
TRUE |
| Device construction |
Built-in device fixed built-in technique |
| DIN rail (top hat rail) mounting optional |
TRUE |
| Complete device with protection unit |
FALSE |
