Varnost izdelkov (GPSR)
Proizvajalčeva koda: LV480751
EAN koda: 3606480070631
Registrirana blagovna znamka: Schneider Electric
Ime proizvajalca: Schneider Electric GmbH
Naslov proizvajalca: Gothaer Str. 29
Poštna številka proizvajalca: 40880
Kraj proizvajalca: Ratingen
Država proizvajalca: Germany
Telefon proizvajalca: +4921173743000
Elektronski kontakt proizvajalca: https://www.se.com/
Kontakt odgovorne osebe za varnost: [email protected]
Država odgovorne osebe za varnost: Nemčija
Dokumenti
Podatkovna tablica 2916208 Schneider Electric LV480751 osiguračka teretna rastavna sklopka 1 St.
Podatkovna tablica 2916208 Schneider Electric LV480751 osiguračka teretna rastavna sklopka 1 St.
Informacije 2916208 Schneider Electric LV480751 osiguračka teretna rastavna sklopka 1 St.
Informacije 2916208 Schneider Electric LV480751 osiguračka teretna rastavna sklopka 1 St.
Informacije 2916208 Schneider Electric LV480751 osiguračka teretna rastavna sklopka 1 St.
Tehnički podaci
| Vrsta proizvoda |
osiguračka teretna rastavna sklopka |
|---|---|
| Sadržaj |
1 St. |
| Tip |
LV480751 |
| Cable entry |
Other |
| Rated permanent current Iu |
100 A |
| Number of poles |
3 |
| Conditioned rated short-circuit current Iq |
80 kA |
| Degree of protection (IP), front side |
IP3X |
| Suitable for fuses |
NH000 |
| Motor drive integrated |
FALSE |
| Type of electrical connection of main circuit |
Screw connection |
| Version as emergency stop installation |
FALSE |
| Type of control element |
Other |
| Version as main switch |
TRUE |
| Version as safety switch |
TRUE |
| Rated short-time withstand current lcw |
3.6 kA |
| Suitable for floor mounting |
FALSE |
| Suitable for front mounting |
TRUE |
| Suitable for busbar mounting |
TRUE |
| Max. rated operation voltage Ue AC |
690 V |
| With error protection |
TRUE |
| Motor drive optional |
FALSE |
| Position control element |
Front side |
| Equipped with connectors |
TRUE |
