Varnost izdelkov (GPSR)
Proizvajalčeva koda: TMH2GDB
EAN koda: 3606480752216
Registrirana blagovna znamka: Schneider Electric
Ime proizvajalca: Schneider Electric GmbH
Naslov proizvajalca: Gothaer Str. 29
Poštna številka proizvajalca: 40880
Kraj proizvajalca: Ratingen
Država proizvajalca: Germany
Telefon proizvajalca: +4921173743000
Elektronski kontakt proizvajalca: https://www.se.com/
Kontakt odgovorne osebe za varnost: [email protected]
Država odgovorne osebe za varnost: Nemčija
Dokumenti
Podatkovna tablica 2913239 Schneider Electric TMH2GDB modul za proširenje
Podatkovna tablica 2913239 Schneider Electric TMH2GDB modul za proširenje
Informacije 2913239 Schneider Electric TMH2GDB modul za proširenje
Informacije 2913239 Schneider Electric TMH2GDB modul za proširenje
Informacije 2913239 Schneider Electric TMH2GDB modul za proširenje
Upute za rad i sigurnost 2913239 Schneider Electric TMH2GDB modul za proširenje
Tehnički podaci
| Vrsta proizvoda |
modul za proširenje |
|---|---|
| Tip |
TMH2GDB |
| Proizvođač-br. dijela |
TMH2GDB |
| Built-in depth |
63 mm |
| Suitable for safety functions |
FALSE |
| Screen diagonal |
2.75 mm |
| Voltage type (supply voltage) |
DC |
| Supporting protocol for LON |
FALSE |
| Number of HW-interfaces industrial Ethernet |
0 |
| Number of HW-interfaces RS-232 |
0 |
| Number of HW-interfaces RS-422 |
0 |
| Number of HW-interfaces RS-485 |
0 |
| Number of HW-interfaces serial TTY |
0 |
| Number of HW-interfaces USB |
0 |
| Number of HW-interfaces parallel |
0 |
| Number of HW-interfaces other |
1 |
| Supporting protocol for TCP/IP |
FALSE |
| Supporting protocol for ASI |
FALSE |
| Supporting protocol for PROFIBUS |
FALSE |
| Supporting protocol for CAN |
FALSE |
| Supporting protocol for INTERBUS |
FALSE |
| Supporting protocol for KNX |
FALSE |
| Supporting protocol for Modbus |
FALSE |
| Supporting protocol for Data-Highway |
FALSE |
| Supporting protocol for DeviceNet |
FALSE |
| Supporting protocol for SUCONET |
FALSE |
| Supporting protocol for other bus systems |
TRUE |
| Colour display |
FALSE |
| Number of colours of the display |
1 |
| Number of pixels, horizontal |
240 |
| Number of pixels, vertical |
160 |
| Number of function buttons, programmable |
4 |
| With numeric keyboard |
FALSE |
| With alpha numeric keyboard |
FALSE |
| With message indication |
TRUE |
| With message system (incl. buffer and confirmation) |
TRUE |
| Process value representation (output) possible |
FALSE |
| Process default value (input) possible |
FALSE |
| With recipes |
FALSE |
| Number of password levels |
1 |
| With printer output |
FALSE |
| Number of online languages |
6 |
| Additional software components, loadable |
TRUE |
| Degree of protection (IP), front side |
IP65/IP67 |
| With SW interfaces |
TRUE |
| Width of the front |
126 mm |
| Height of the front |
80 mm |
| Suitable for rail mounting |
TRUE |
| Supporting protocol for SERCOS |
FALSE |
| Supporting protocol for INTERBUS-Safety |
FALSE |
| Number of interfaces PROFINET |
0 |
| Number of HW-interfaces wireless |
0 |
| Wall mounting/direct mounting |
TRUE |
| Radio standard Bluetooth |
FALSE |
| Radio standard WLAN 802.11 |
FALSE |
| IO link master |
FALSE |
| Supporting protocol for AS-Interface Safety at Work |
FALSE |
| Supporting protocol for DeviceNet Safety |
FALSE |
| Supporting protocol for EtherNet/IP |
FALSE |
| Supporting protocol for Foundation Fieldbus |
FALSE |
| Supporting protocol for PROFINET CBA |
FALSE |
| Supporting protocol for PROFINET IO |
FALSE |
| Supporting protocol for PROFIsafe |
FALSE |
| Supporting protocol for SafetyBUS p |
FALSE |
| Type of display |
STN |
| Number of grey-scales/blue-scales of display |
0 |
| Radio standard GPRS |
FALSE |
| Radio standard GSM |
FALSE |
| Mobile communications standard 3G (UMTS) |
FALSE |
| Number of buttons with LED |
0 |
| Number of system buttons |
6 |
| Touch technology |
Other |
