Opis
PROFIBUS FC Trailing Cable, PROFIBUS trailing cable, max. Acceleration 4 m/QS min. 3 million bending cycles min. Bending radius approx. 120 mm 2-wire shielded, sold by the meter delivery unit max. 1000 m minimum order quantity 20 m. Highly flexible bus cable specially designed for fast installation, for use in continuous motion in a trailing cable.Time is saved thanks to easy and quick on-site installation. Reliable shield contact and strain relief as well as efficient EMC shielding. Network is not sensitive to interferences due to shielded, twisted-pair cable. System-wide grounding concept can be implemented using the external shield of the bus cable and the grounding terminals on the bus terminal. Silicone-free, therefore suitable for use in the automotive industry (for example on paint lines). Easy length measurement thanks to printed meter marking.
Varnost izdelkov (GPSR)
Proizvajalčeva koda: 6XV18303EH10
EAN koda: 4019169400411
Registrirana blagovna znamka: Siemens
Ime proizvajalca: Siemens AG
Naslov proizvajalca: Siemenspromenade 2
Poštna številka proizvajalca: 91058
Kraj proizvajalca: Erlangen
Država proizvajalca: Germany
Telefon proizvajalca: +498938035491
Elektronski kontakt proizvajalca: https://www.siemens.com/
Kontakt odgovorne osebe za varnost: [email protected]
Država odgovorne osebe za varnost: Nemčija
Dokumenti
Podatkovna tablica 2875969 Siemens 6XV18303EH10 1 St.
Podatkovna tablica 2875969 Siemens 6XV18303EH10 1 St.
Upute za rad i sigurnost 2875969 Siemens 6XV18303EH10 1 St.
Upute za rad i sigurnost 2875969 Siemens 6XV18303EH10 1 St.
Upute za rad i sigurnost 2875969 Siemens 6XV18303EH10 1 St.
Upute za rad i sigurnost 2875969 Siemens 6XV18303EH10 1 St.
Upute za rad i sigurnost 2875969 Siemens 6XV18303EH10 1 St.
Upute za rad i sigurnost 2875969 Siemens 6XV18303EH10 1 St.
Upute za rad i sigurnost 2875969 Siemens 6XV18303EH10 1 St.
Upute za rad i sigurnost 2875969 Siemens 6XV18303EH10 1 St.
Upute za rad i sigurnost 2875969 Siemens 6XV18303EH10 1 St.
Upute za rad i sigurnost 2875969 Siemens 6XV18303EH10 1 St.
Upute za rad i sigurnost 2875969 Siemens 6XV18303EH10 1 St.
Tehnički podaci
| Tip |
6XV1830-3EH10 |
|---|---|
| Proizvođač-br. dijela |
6XV18303EH10 |
| Sadržaj |
1 St. |
| RoHS-konforno |
Da |
| Material core insulation |
Other |
| Core identification |
Colour |
| Flame retardant |
No |
| Stranding element |
Pairs |
| Colour outer sheath |
Other |
| Category |
Other |
| Diameter conductor |
0.67 mm |
| Screen over stranding element |
None |
| Screen over stranding |
Foil + braiding |
| Material outer sheath |
Polyurethane (PUR) |
| Permitted cable outer temperature during assembling/handling |
-40-60 °C |
| Permitted cable outer temperature after assembling without vibration |
-40-60 °C |
| Number of stranding elements |
1 |
| Number of cores |
2 |
| Suitable for underground installation |
FALSE |
| Stranding |
Bundle |
| Outer diameter approximate |
8 mm |
| Low smoke (according to EN 61034-2) |
FALSE |
| Conductor surface |
Bare |
| Reaction-to-fire according to EN 13501-6: Class |
Eca |
| Specification material outer sheath |
Other |
