Varnost izdelkov (GPSR)
Proizvajalčeva koda: 111683
EAN koda: 4015081112425
Registrirana blagovna znamka: Eaton
Ime proizvajalca: Eaton Electric GmbH
Naslov proizvajalca: Hein-Moeller-Str. 7-11
Poštna številka proizvajalca: 53115
Kraj proizvajalca: Bonn
Država proizvajalca: Germany
Telefon proizvajalca: +496951709895
Elektronski kontakt proizvajalca: https://www.eaton.com
Kontakt odgovorne osebe za varnost: [email protected]
Država odgovorne osebe za varnost: Nemčija
Dokumenti
Podatkovna tablica 2498628 Eaton CS-44/150 zidno kućište 400 x 400 x 150 siva 1 St.
Tehnički podaci
| Vrsta proizvoda |
zidno kućište |
|---|---|
| Vrsta zaštite |
IP66 |
| Boja |
siva |
| Širina |
400 mm |
| Visina |
400 mm |
| Sadržaj |
1 St. |
| Tip |
CS-44/150 |
| dim. |
(Š x V x D) 400 x 400 x 150 mm |
| RoHS-konforno |
Da |
| Proizvođač-br. dijela |
111683 |
| Dubina |
150 mm |
| Colour |
Grey |
| Width |
400 mm |
| Height |
400 mm |
| Depth |
150 mm |
| RAL-number |
7035 |
| With mounting plate |
TRUE |
| Number of doors |
1 |
| Number of locks |
1 |
| Suitable for wall mounting |
TRUE |
| Pre-stamping |
FALSE |
| With glazed door |
FALSE |
| Couplable |
FALSE |
| Material quality |
Other |
| Material |
Steel |
| Impact strength |
IK10 |
| Degree of protection (IP) |
IP66 |
| Number of connector holes |
0 |
| Suitable for outdoor set-up |
FALSE |
| Suitable for metrical mounting |
TRUE |
| Mounting plate depth-adjustable |
FALSE |
| With ventilation door |
FALSE |
| Surface finishing |
Powder coating |
| With rear door |
FALSE |
| Suitable for wall built-in |
TRUE |
| With cover |
TRUE |
| With door |
TRUE |
| Pitched roof |
FALSE |
| Pole fastening |
TRUE |
| Transparent cover |
FALSE |
| Degree of protection (NEMA) |
12 |
| Thermal dissipation (Delta T = 20 K) according to IEC/TR 60890 |
25 W |
| Max. permitted load of the enclosure according to IEC 62208 |
2250 N |
| Max. permitted load of the door(s) according to IEC 62208 |
250 N |
| Max. permitted load of the mounting plate according to IEC 62208 |
2000 N |
| Floor standing wall model |
TRUE |
| Freestanding |
FALSE |
| Corner model |
FALSE |
| Intermediate mounting |
TRUE |
