Varnost izdelkov (GPSR)
Proizvajalčeva koda: 22.64.0.230.4610
EAN koda: 8012823376592
Registrirana blagovna znamka: Finder
Ime proizvajalca: FINDER GmbH
Naslov proizvajalca: Hans-Böckler-Str. 44
Poštna številka proizvajalca: 65468
Kraj proizvajalca: Trebur
Država proizvajalca: Germany
Telefon proizvajalca: +490614720330
Elektronski kontakt proizvajalca: https://www.findernet.com/de
Kontakt odgovorne osebe za varnost: [email protected]
Država odgovorne osebe za varnost: Nemčija
Dokumenti
Tehnički podaci
| Vrsta proizvoda |
instalacijski kontaktor |
|---|---|
| Tip |
22.64.0.230.4610 |
| Broj polova |
4-polni |
| Vrsta kontakta |
2 otvarač |
| Nazivni napon |
440 V/AC |
| Preklopni napon (maks.) |
230 V DC/AC |
| Trajna struja (maks.) |
63 A |
| Vrsta zaštite |
IP20 |
| Sadržaj |
1 St. |
| RoHS-konforno |
Da |
| Width |
53.5 |
| Height |
95.8 mm |
| Depth |
63.1 mm |
| Suitable for distribution board |
TRUE |
| Rated operation power at AC-3, 400 V |
15 kW |
| Number of normally open contacts as main contact |
2 |
| Number of normally closed contacts as main contact |
2 |
| Number of auxiliary contacts as normally open contact |
0 |
| Number of auxiliary contacts as normally closed contact |
0 |
| Rated operation current Ie at AC-3, 400 V |
30 A |
| Rated operation current Ie at AC-1, 400 V |
63 A |
| Rated control supply voltage AC 50 Hz |
230-230 V |
| Rated control supply voltage AC 60 Hz |
230-230 V |
| Rated control supply voltage DC |
230-230 V |
| Type of electrical connection of main circuit |
Screw connection |
| Operating voltage AC 50 Hz |
196-264 V |
| Operating voltage AC 60 Hz |
196-264 V |
| Voltage type for actuating |
AC/DC |
