Varnost izdelkov (GPSR)
Proizvajalčeva koda: 266024
EAN koda: 4015082660246
Registrirana blagovna znamka: Eaton
Ime proizvajalca: Eaton Electric GmbH
Naslov proizvajalca: Hein-Moeller-Str. 7-11
Poštna številka proizvajalca: 53115
Kraj proizvajalca: Bonn
Država proizvajalca: Germany
Telefon proizvajalca: +496951709895
Elektronski kontakt proizvajalca: https://www.eaton.com
Kontakt odgovorne osebe za varnost: [email protected]
Država odgovorne osebe za varnost: Nemčija
Dokumenti
Tehnički podaci
| Vrsta proizvoda |
teretna rastavna sklopka |
|---|---|
| Tip |
N3-4-630 |
| Veličina |
3 |
| Broj polova |
4-polni |
| Preklopni napon (maks.) |
690 V/AC |
| Vrsta montaže (Relej) |
fiksna instalacija |
| Priključak |
vijak |
| Vrsta zaštite |
IP20 |
| Sadržaj |
1 St. |
| RoHS-konforno |
Da |
| Width |
185 |
| Height |
275 mm |
| Depth |
159 mm |
| Rated operation power at AC-3, 400 V |
0 kW |
| Number of auxiliary contacts as normally open contact |
0 |
| Number of auxiliary contacts as normally closed contact |
0 |
| Number of poles |
4 |
| Rated operating voltage |
690-690 V |
| Conditioned rated short-circuit current Iq |
0 kA |
| Degree of protection (IP), front side |
IP20 |
| Number of auxiliary contacts as change-over contact |
0 |
| Number of switches |
1 |
| Interlockable |
TRUE |
| Motor drive integrated |
FALSE |
| Type of electrical connection of main circuit |
Screw connection |
| Version as emergency stop installation |
TRUE |
| Type of control element |
Rocker lever |
| Version as main switch |
TRUE |
| Version as safety switch |
FALSE |
| Version as maintenance-/service switch |
TRUE |
| Rated operation power at AC-23, 400 V |
315 kW |
| Rated short-time withstand current lcw |
12 kA |
| Colour control element |
Black |
| Suitable for floor mounting |
TRUE |
| Suitable for front mounting 4-hole |
FALSE |
| Suitable for front mounting centre |
FALSE |
| Suitable for distribution board installation |
TRUE |
| Suitable for intermediate mounting |
TRUE |
| Max. rated operation voltage Ue AC |
690 V |
| Motor drive optional |
TRUE |
| Voltage release optional |
TRUE |
| Device construction |
Built-in device fixed built-in technique |
| Rated permanent current at AC-21, 400 V |
0 A |
| Switching power at 400 V |
0 kW |
| Version as reversing switch |
FALSE |
| Rated permanent current at AC-23, 400 V |
0 |
| Degree of protection (NEMA) |
Other |
| With pre-assembled cabling |
FALSE |
