Eaton 262730 ETR2-44 vremenski relej 1 St.

Marka Eaton

(0 ocen)

139,99 EUR

(= 1.054,75 kn)

149,99 EUR 7% popusta

Kod proizvoda: 1973274
EAN: 4015082627300
Procijenjena isporuka:23.10.2026 - 27.10.2026

Opis

Elektronički relej za mjerenje vremena ETR2, širine 17,5 mm, vremenski raspon 0,05s-100h, 1 preklopni kontakt treperi 2 puta

Ovaj tekst je strojno preveden.

Varnost izdelkov (GPSR)

Proizvajalčeva koda: 262730

EAN koda: 4015082627300

Registrirana blagovna znamka: Eaton

Ime proizvajalca: Eaton Electric GmbH

Naslov proizvajalca: Hein-Moeller-Str. 7-11

Poštna številka proizvajalca: 53115

Kraj proizvajalca: Bonn

Država proizvajalca: Germany

Telefon proizvajalca: +496951709895

Elektronski kontakt proizvajalca: https://www.eaton.com

Kontakt odgovorne osebe za varnost: [email protected]

Država odgovorne osebe za varnost: Nemčija

Dokumenti

Podatkovna tablica 1973274 Eaton 262730 ETR2-44 vremenski relej 1 St.

Upute za rad i sigurnost 1973274 Eaton 262730 ETR2-44 vremenski relej 1 St.

Tehnički podaci

Vrsta proizvoda	vremenski relej
Tip	ETR2-44
Priključak	vijak
Funkcije	žmigalo, počinje impulsom žmiglo, počinje pauzom
min. pogonski napon	24 V DC/AC
Pogonski napon maks.	240 V/AC 48 V/DC
Pogonski napon	24 - 240, 48 V/AC, V/DC
Prebacivanje struje (maks.)	3 A
Min. temperatura	-25 °C
Maks. temperatura	+60 °C
Širina	18 mm
Visina	70 mm
Dubina	63 mm
dim.	(Š x V x D) 18 x 70 x 63 mm
Sadržaj	1 St.
Priključak	vijčani priključak
Nominal current	3 A
Width	17.5 mm
Height	70 mm
Depth	63 mm
Complete with socket	FALSE
Remote operation possible	TRUE
Suitable as remote control	FALSE
Function flashing, starting with pause, fixed time	TRUE
Function flashing, starting with pulse, fixed time	TRUE
Clock function, starting with pause, variable	TRUE
Clock function, starting with pulse, variable	TRUE
With semiconductor output	FALSE
Function delay-on energization	FALSE
Function floating contact on energization	FALSE
Function star-delta	FALSE
Time range	0.05-360000 s
Function delay on de-energization	FALSE
Function floating contact on de-energization	FALSE
Function pulse shaping	FALSE
Type of electric connection	Screw connection
Rated control supply voltage AC 50 Hz	24-240 V
Rated control supply voltage AC 60 Hz	24-240 V
Rated control supply voltage DC	24-240 V
Voltage type (operating voltage)	AC/DC
Degree of protection (IP)	IP20
Number of outputs, undelayed, normally closed contact	0
Number of outputs, undelayed, normally open contact	0
Number of outputs, undelayed, change-over contact	0
Number of outputs, delayed, normally closed contact	0
Number of outputs, delayed, normally open contact	0
Number of outputs, delayed, change-over contact	0
Pluggable on auxiliary contact block	FALSE
Outputs, reversible delayed/undelayed	FALSE
Suitable for DIN rail (top hat rail) mounting	TRUE
Operating voltage AC 50 Hz	24-240 V
Operating voltage AC 60 Hz	24-240 V
Operating voltage DC	24-48 V
Voltage type for actuating	AC/DC
Suitable for front mounting	FALSE
